Defining 0x50 0x00 as unstructured taproot annex data

Protocol Design
1

Hi all,

I would like to reopen the discussion around unstructured data in the taproot annex, with a narrower scope than previous proposals.

This has been discussed before. BIP341 introduced the annex as a witness element starting with 0x50. The annex, or the lack of annex, is covered by the signature, contributes to transaction weight, and is otherwise ignored by taproot validation. BIP341 also warns users not to include an annex until its meaning is defined, because a future soft fork could assign meaning to it.

Antoine Riard (@ariard) later proposed a structured annex format using TLV-like records. Joost Jager (@joostjager) then proposed making a limited form of unstructured annex standard, first on the mailing list and then in Bitcoin Core PR #27926. That proposal used annexes starting with 0x00 for unstructured data. The Core PR also included relay-policy rules: if one input committed to an annex, all inputs had to commit to an annex; empty annexes were allowed; and unstructured annex data was limited to 256 bytes. The PR was closed for inactivity.

My reading is that the discussion started from the idea of 0x00 as free-form annex data, but then moved into relay policy, standardness limits, multiparty concerns, TLV integration, and concrete use cases before the basic documentation question was settled.

A later direction in the thread was to make unstructured annex data standard only under restrictive policy rules. I am intentionally asking a smaller question here: whether the raw 0x50 0x00 <bytes> form should be documented as the unstructured annex form, independent of relay policy.

I would like to separate those questions and focus only on the consensus-level interpretation of:

0x50 0x00 <bytes>

where 0x50 is the existing annex marker, 0x00 marks the annex as unstructured, and the remaining bytes are left to the application that created them.

This is not a proposal to change consensus rules. The annex is already valid at consensus level. The proposal is only to define this form as unstructured annex data, so that future consensus changes do not assign another meaning to the same form.

The motivation is that the underlying incentive remains open. Witness bytes have a lower weight than non-witness bytes. This gives applications placing data on-chain a strong reason to use witness-based encodings.

I am not arguing that data embedding is desirable. The point is that the incentive exists anyway. If applications are economically pushed toward witness-based data encodings, it seems better to define a form that avoids the worse side effects of other constructions. The annex is relevant for that discussion because it is not script, it does not create UTXOs, it is signed by the spending input, it is counted in transaction weight, and BIP341 already specifies that it is otherwise ignored by taproot validation.

What is missing is a defined unstructured form. Without that, applications using the annex still have to worry that their data may conflict with some future consensus meaning.

The proposal is therefore:

0x50 0x00 <bytes>

means unstructured taproot annex data, with no consensus interpretation for the bytes after 0x00.

Future structured annex proposals should avoid giving another meaning to this same form. This should not conflict with the earlier structured-annex work; it only asks that structured encodings avoid the 0x50 0x00 prefix.

This post is intentionally not about relay policy. It does not propose making such transactions standard. It does not propose a default mempool size limit. It does not propose that default relay accept large annexes. It does not require all inputs to carry an annex. It also does not try to settle the multiparty annex-inflation concern, beyond acknowledging that it matters for policy and protocol design.

I am looking for feedback on the narrow consensus-level idea: whether 0x50 0x00 <bytes> should be treated as the unstructured annex form, and whether there are reasons future consensus extensions would need to use that same form for something else.

If the feedback is positive, I will try to write this up as a short BIP.

References

BIP341:

BIP141:

Taproot Annex Format proposal:

Standardisation of an unstructured taproot annex:

Bitcoin Core PR #27926:

Ord issue mentioning the need for an unstructured annex carve-out:

Best, LesLie (0300dbdd1b)

1 Like
2

Yeah I browsed again the joost pull request, somehow if you’re going to use the annex in a multi-party transaction it’s hard in practice to avoid inflation size and some kinds of mempools / fee-estimation games (e.g inflating the annex data tag to adversarially get txn stucking). Maybe encouraging people to do 1-input / 1-output transaction would simplify early deployment for now.

In practice, going to support this for any full-node mempool implementation, there will be a need at minima some mempool acceptance at-the-choice policy (do you accept by default annex equals to MAX_BLOCK_SIZE ?). On the direction of at-the-choice policy there has been the old work of Jorge Timon when he was at blockstream iirc to abstract the mempool interface with a CPolicy interface for their sidechain usecases or other things. There is also the idea I proposed a while back on opt-in policy encoded at the transaction level based on my lightning experience to allow different categories of transactions to co-exist on the network.

I’m not going to comment on data embedding or whatever use case desirability. We have already the Satoshi whitepaper laying out a foundational analysis for the game-theory security of bitcoin and in addition all the security edge cases or structural gaps, that we as a community have learnt along the journey. If there are shortcomings and things to fix, we should go for consensus changes, relying on policy consistency will be always a weaker assumption.

Back in 2021 I did organize a IRC working group on public communication channels to allow anyone in the world to be able to comment, collect ideas and propose improvements on proposed policy rules changes, among other things mempoolfullrbf. Between the time full-rbf as a change was proposed and the time a pull request was introduced, I did leave a year or two release cycles of bitcoindfor people to come with substantial objections or migrate their softwares. Even that wasn’t enough for some people (e.g for Muun wallets iirc).

Retrospectively, I think those reliability relay workshops done in an open fashion were a good development practice. Defining unilaterally some software format doesn’t work when you have softwares written by different folks that have to be inter-compatible for a “functionality” to work effectively I think you might encounter the same issue with a data-only annexif you wish to have it propagating reliably to miners, at least the question did arise with mempoolfullrbf to have a temporarily NODE_FULL_RBF node bit.
